| Impedance | 75 ohm |
| Frequency Range | 0 – 12GHz |
| Return Loss (*) | 15dB (5MHz – 1.5GHz) |
| 10dB (1.5GHz – 3GHz) | |
| 7dB (3GHz – 6GHz) | |
| 4dB (6GHz – 12GHz) |
(*) The electrical performance listed above is complied with SMPTE ST 2082-1. Once it needs to be operated with stricter specification, please highlight your requirement to our attention at RFQ stage.
| Body | Brass/Nickel |
| Insulator | PTFE |
| Inner Contact | Beryllium Copper/Gold |
Any other specific material or plating, please highlight your requirement to our attention at RFQ stage.
| Mating Cycles | 500 |
| Temperature Range | -65℃ to 165℃ |
Our design is to offer 4K and Ultra-HD quality signals for high-resolution uncompressed video transmission.
| General P/N | PCB Thickness (*) |
| HB203 | 0.8mm |
| 1.0mm | |
| 1.6mm |
(*) Any other specific PCB thickness, please highlight your requirement at RFQ stage.
Ultra Tiny BNC (75 ohm)(12GHz) Terminator Cable : N/A
